Products Series

Seat Belt Buckles (CD-0300A Series)

Product Information

Available Model Colors

Available Match Colors

Inquiry

Available Model

CD-0300A-B01

CD-0306A-A01

Available Match

About CA-0300A series Seat Belts

CA-0300 series is design to be as easy as possible piece to keep safety and comfort.

It can be a replacement part for most of current existing one.

● user friendly

● great replacement part

● fit universal purpose

Auto Part

CY-015A

✔ Dimension : 42.3mm X 49.5mm
✔ Material : Steel (Chrome)
✔ Webbing hole diameter : 26.9mm

Female-Buckle Specification

CA-0300A

✔Dimension : 47mm X 68mm
✔Material : S50C

CA-0303A1

✔Dimension : 47mm X 68mm
✔Material : S50C

CA-0306A

✔Dimension : 47mm X 68mm
✔Material : S50C

CA-0310A1

✔Dimension : 47mm X 68mm
✔Material : S50C

CA-0350A

✔Dimension : 47mm X 68mm
✔Material : S50C

CA-0360A

✔Dimension : 47mm X 68mm
✔Material : S50C

Male-Buckle Specification

CW-3001

✔Dimension : 74mm X 68.5mm
✔Material : S50C + PU
✔Webbing hole diameter : 50mm

CW-3002

✔Dimension : 49.3mm X 47mm
✔Material : S50C
✔Webbing hole diameter : 30mm

CW-3003

✔Dimension : 49.5mm X 41.6mm
✔Material : S50C
✔Webbing hole diameter : 25.7mm

CW-3004

✔Dimension : 49.2mm X 41mm
✔Material : S50C
✔Webbing hole diameter : 30mm

CW-3005A

✔Dimension : 49.3mm X 47mm
✔Material : S50C + Plastic
✔Webbing hole diameter : 26.8mm

CW-3111

✔Dimension : 70mm X 43.3mm
✔Material : S50C + Plastic
✔Webbing hole diameter : 51mm

CW-3211 (Thick)

✔Dimension : 70mm X 61.8mm
✔Material : S50C + Plastic
✔Webbing hole diameter : 51mm

CW-3222 (Thin)

✔Dimension : 70mm X 61.8mm
✔Material : S50C + Plastic
✔Webbing hole diameter : 51mm
